Diaphragm Seals and Isolators
Find the optimal Ashcroft® diaphragm seals and isolation rings for your application by using the filtering options provided.
Ashcroft® diaphragm seals and isolation rings protect valuable instruments from potential damage caused by corrosive media or clogging from sludge or slurries, especially in wastewater processing. Diaphragm seals are offered in a variety of configurations with a wide selection of compatible wetted materials, such as 316 stainless steel, Monel and Tantalum. Isolation rings are available in different diameters for integration into piping systems. They provide a contiguous, flexible inner wall that deflects to equally pressurize the fill fluid into the pressure measuring device.Showing 1-12 of 10 products
100-101 Threaded Diaphragm Seals
The Ashcroft® 100 and 101 threaded diaphragm seals protect pressure measuring instruments. Used when process compatibility is required, these are also applied when media exhibit...
510-511 All-Welded Diaphragm Seals
The Ashcroft® 510 and 511 compact, all-welded diaphragm seals protect pressure measuring instruments. Used to ensure process compatibility, they are also applied when process media...
310-315 Mini-Diaphragm Seals
The Ashcroft® 310 and 315 mini-diaphragm seals protect pressure measuring instruments. Used to ensure process compatibility, they are also applied when process media exhibit pulsation...
740-741 High-Displacement Diaphragm Seals
The Ashcroft® 740 and 741 high-displacement diaphragm seals are used with low-ranged instruments or high static pressure differential pressure gauges with low differential pressure. Used...
330 All-Welded Flush Mini Diaphragm Seal
The Ashcroft® 330 all-welded flush mini-diaphragm seal protects pressure measuring instruments. Used to ensure process compatibility, they are also applied when process media exhibit pulsation...
311-312 Midi-Diaphragm Seals
The Ashcroft® 311 and 312 midi-diaphragm seals are fitted in confined areas to protect measuring instruments. Used to ensure process compatibility, they are also applied...
300-301 Threaded Diaphragm Seals
The Ashcroft® 300 and 301 threaded diaphragm seals protect pressure measuring instruments. Used when process compatibility is required, these are also applied when media exhibits...
400-401 All-Welded Diaphragm Seals
The Ashcroft® 400 and 401 all-welded diaphragm seals protect pressure measuring instruments. Used to ensure process compatibility, they are also applied when process media exhibit...
500-501 All-Welded Diaphragm Seals
The Ashcroft® 500 and 501 all-welded diaphragm seals protect pressure measuring instruments. Used to ensure process compatibility, they are also applied when process media exhibit...
